Excavation Construction
Shenhua Group Bayannur Air-supported Coal Storage Project
Share:
Project Overview
Shenhua Group, one of the world's largest coal companies, has long faced problems such as coal dust pollution and coal freezing in winter at its Bayannur coal mine's open-pit coal yard, which seriously affects coal quality and transportation efficiency. The coal yard covers approximately 15,000 square meters. To achieve green production, Shenhua Group decided to carry out a complete enclosure renovation of the coal yard.
Challenges
01
The winter temperatures in Bayannur are extremely low, reaching as low as -30°C, making ordinary membrane materials brittle and unusable.
02
The coal mine is located in an area with strong winds and sandstorms, which makes it easy for sand to accumulate on the surface of the membrane material, affecting the airtightness and service life of the air-supported membrane structure.
03
Coal yards have a large coal turnover rate, and the enclosure renovation should minimize the impact on coal transportation.
Solution
Supai customized the SP-MC150 cold-resistant and wind-blown sand-resistant air-supported membrane coal storage system for them. This system uses low-temperature resistant PVDF membrane material, allowing normal operation in environments as low as -40℃; it is equipped with an automatic sand removal system that periodically cleans accumulated sand from the membrane surface; and it adopts a segmented installation method, allowing for gradual modification without affecting coal transportation. A key highlight of the solution is the application of "hot air de-icing" technology, which rapidly melts ice on the membrane surface in winter, ensuring the normal operation of the air-supported membrane structure. Simultaneously, the air-supported membrane structure achieves an IP65 sealing performance, effectively preventing coal dust leakage.
Project Data
|
Project Name |
Place |
Completion Time |
Span |
Length |
Area |
Membrane Material Type |
Wind Resistance Level |
Special Configuration |
|
Shenhua Group Bayannur Air-supported Coal Storage Project |
Bayannur, Inner Mongolia |
June 2025 |
90 meters |
167 meters |
15,000 square meters |
Low-temperature resistant PVDF membrane material |
Level 13 |
Automatic sand removal system, hot air de-icing device |
Outcomes
Coal freezing rate decreased by 95% in winter;
Coal dust emissions have been reduced by 98% .
Coal transportation efficiency decreased by only 5% during the project upgrade;
The service life of the membrane material has been extended to 25 years;
It saves approximately 2 million yuan annually in coal consumption and environmental fines.
Testimonial
"The air-supported membrane coal storage bin has solved our long-standing problems of coal freezing and dust pollution. Its excellent cold resistance and sand resistance performance ensure the normal operation of our coal mine in harsh environments."
